Failure to properly destroy secret and sensitive data on end-of-life IT assets can lead to serious breaches of data-protection. This violates privacy policies, causes compliance problems, and adds extra cost. MEMXPRO introduces its data self-destruction SSD, using just one click to physically destroy all data on an SSD. Combining AES data encryption and high-power voltage supply, the design ensures that data is permanently made inaccessible and irrecoverable. Through a preset software command or hardware button, an over-voltage current is applied to the controller which destroys it completely.

Storage needs to be securely destroyed when:
  • Your storage devices reach their end of life and need replacement.
  • Your company and your customers' information needs to be securely disposed of.
  • Your confidential and sensitive data or software is at risk from theft or hacking.



Major application scenarios



High-level information security for defense and government. Security and sensitive data in information institutions and enterprises. Confidential data and software protection in gaming machines or factory facilities.



Triggered by Hardware or Software



Software Button
  • Install the customized utility
  • Just click the software button
    		• Hardware Button
  • Pin headers are reserved on the SSD
  • Easy connection to the button
    		•




      Data is irrecoverable once data self-destructible SSD is triggered by the hardware buttons.


    MEMXPRO Data Self-destruction SSD benefits



    Complete protection:
    After the controller dies, Flash ICs can NEVER be reread.     		No safety concerns:
    The high-level voltage
    only destroys the
    controller IC.
    Cost-saving:
    Motherboards do not need to be redesigned.     		Provide SDK to customer:
    Supports Linux and Windows




    Product specifications



    2.5" SSD RM31
    Interface SATA III
    Form Factor 2.5" SSD (SFF-8201)
    Flash Type MLC
    Max. Channel 4
    Density 64GB~512GB
    Sequential R/W (MB/sec, max.) 545/453
    Operating Temperature 0°C~+70°C/-25°C~+85°C/-40°C~+85°C
    Max. Power Consumption 6W (5Vx1.2A)
    Dimension (LxWxH/mm) 100x69.85x9.3
    External DRAM Buffer ✓
    Thermal Sensor ✓
